Mainboard Replacement and Mainboard Upgrade Instructions

Here are the video instructions on Facebook and YouTube for Mainboard (Main PCB) Replacement in Melco EMT16 (including EMT16Plus) and Bravo2 machines. This video covers direct replacement and also upgrade steps, when applicable.

These instructions are also found in the online Technical Manuals for EMT16Bravo and XTS machines.

Important to remember when replacing your machine's mainboard:

  • Always be sure the machine is Powered OFF.
  • Take pictures of the mainboard and cable positions before disconnecting.  This will be a helpful reference if you are unsure of certain cable connections when installing the new mainboard.
